Till settings (printer, scale, customer display)

Use this page when you need to pair or re-pair a printer, scale, or customer display on the till, or change how the till behaves at the counter.

Goal

Core App demo store — screens may differ slightly by version.

You need to set up or change the till's hardware (receipt printer, scale, customer-facing display, cash drawer) so sales work the way your store expects.

Where this happens

• On the till (Retail POS App or Restaurant POS App): open Settings from the till home screen or drawer (Restaurant POS route /settings, view SettingsView.vue).
• In the back office (Core App): the till's hardware registration lives at the franchise level — your franchise admin can re-register a device.

Prerequisites

• You are signed in to the till with a role that has Settings permission.
• The hardware is plugged in (USB or network) or paired over Bluetooth / Wi-Fi.
• Your franchise admin has approved the device; some franchises only allow approved hardware.

Steps

1. Open Settings on the till

On the till home screen or drawer, open Settings (route /settings). The screen opens with the page title Device Settings and the General Settings tab active. On desktop the other tabs are: Printer Settings, Special Settings, Display Settings, LED Display. On mobile the same tabs appear with shorter labels: General, Printer, Special, Display, LED.

The header bar shows your device name plus these buttons: Email Settings, Table Settings, Table Logs, Save Settings, Switch Store, Sign Out.

2. Set up the printer and cash drawer (Printer Settings tab)

1. Tap Printer Settings.
2. Pick Receipt Type (Normal / NonGraphical2 / Unbranded / Basic / 55mm) — controls the customer-receipt format.
3. Pick Bill Slip Type (Normal / Normal 2 / Reduced / Basic) — controls the bill-slip format.
4. Pick the Main Receipt Printer from the printers available on the till.
5. Pick the Cash Drawer dropdown — the printer that controls the cash-drawer kick.
6. (Optional) assign Printer 1, Printer 2, Printer 3 for additional station printers.
7. Tap Save Settings to persist.

3. Pair the scale (General Settings tab — Scale Configuration)

1. On General Settings, scroll to Scale Configuration.
2. Tick Use Scale Integration to enable the scale.
3. Pick the Scale COM Port (tap Refresh to re-scan ports).
4. Pick the Baud Rate (9600 / 19200 / 38400 / 115200), Data Bits (7 / 8), and Parity (None / Odd / Even) the scale uses.
5. Pick the Scale Model / Protocol — Standard (Default), Toledo / Mettler, CAS / Basic Scale, Sangjie, Digi, Accumulate (Fragmented Data), or Custom (Decimal).
6. If you picked Custom, set Decimal Places (2 / 3 / 4).
7. Pick the Scale Unit (Kilograms / Grams) and Scale Characters (RAW / ASCII).
8. Use Capture Data (1s) to grab a one-second sample of the scale output, then Save Local Config.
9. Place a known weight on the scale to confirm the reading matches.

4. Pair the customer-facing display (Display Settings tab)

1. Tap Display Settings.
2. Tap Detect Available Screens to enumerate connected displays.
3. Pick the Customer Display Screen from the dropdown (the screen currently showing the POS is excluded).
4. Tick Enable Customer Display.
5. Use Open Customer Display to launch the window; Close Customer Display to dismiss it.
6. (Optional) set Promotions Folder to a directory of JPG / PNG / GIF images and use Load Promotional Images to preview them on the customer display.

5. Configure the LED pole display (LED Display tab)

1. Tap LED Display.
2. Pick the Serial Port for the LED display.
3. Pick the Baud Rate (2400 / 9600 / 19200 / 38400).
4. Pick the Value to Display during transactions (Sale Total / Paid Amount / Change).
5. Tick Enable LED Display.
6. Tap Test LED Display (120) to send a test value to the LED; tap Save LED Config to persist.

6. Save and restart the till (if asked)

Some settings only apply after a till restart. If the screen asks, close the till app and re-open it; do not power off the device.

Expected result

• Every paired device appears in the relevant Settings tab as enabled / connected.
• A test receipt prints from the paired printer and the cash drawer kicks.
• A test weight shows correctly on the till when placed on the scale.
• The customer display mirrors the running sale total.

Edge cases

• A device is not discovered. Check the cable, network, or Bluetooth pairing; restart the device. If still missing, ask your supervisor — some hardware is only allowed at the franchise level.
• The printer prints the wrong characters. The wrong character set is selected; ask your supervisor to set the correct one in Settings → Printer.
• The scale weight is off. Zero or tare the scale from Settings → General → Scale Configuration, or ask your supervisor to recalibrate.
• The till asks for a registration code. The till is not registered to your franchise yet; contact Support with the till's device ID.
• You cannot see Settings on the till. Your role may not have Settings permission; ask your supervisor.
